| Sr. No. |
Name of the Laboratory |
Name of the Important equipment |
| 1 |
Mechanical Measurements and Metrology |
1. Dial gauge |
| 2. Vernier caliper 300 mm digital |
| 3. Vernier Height Gauge |
| 4. Vernier Depth gauge |
| 5. Bevel Protector |
| 6. Sine Bar |
| 7. Outside micrometer 0-25mm |
| 8. Inside micrometer - 5 - 30 j mm |
| 9. Fillar gauge - 8" |
| 10. Gear tooth vernier - 1-26mm module - (gtv) |
| 11. Dead weight pressure gauge tester |
| 12. Thermometer wet & dry bulb |
| 13. Surface roughness tester |
| 14. Thermometer infrared - mtx-2 |
| 15. Measurement and temperature tutor using thermocouple |
| 2 |
Theory of Machine |
1. Motorised gyroscope |
| 2. Universal governor |
| 3 |
Fluid Power Engineering |
1. Reciprocating pump rig |
| 2. Centrifugal pump test rig |
| 3. Pelton wheel turbine test rig |
| 4. Kaplan turbine test rig |
| 5. Francis turbine test rig |
| 6. Impact of jet apparatus with s.s tank |
| 4 |
Heat and Mass Transfer |
1. HEAT CONDUCTION APAPRATUS |
| 2. THERMAL CONDUCTIVITY OF LIQUID MEASURING |
| 3. HEAT TRANSFER THROUGH COMPOSITE WALL |
| 4. HEAT TRANSFER IN NATURAL CONVECTION |
| 5. HEAT TRANSFER IN FORCED CONVECTION |
| 6. EMISSIVITY MEASUREMENT APPARATUS |
| 7. STEFAN BOLTZMANS APPARATUS - VIPL - 8002 |
| 8. HEAT TRANSFER FROM PIN FIN |
| 9. PARALLEL FLOW / COUNTER FLOW HEAT EXCHANGER |
| 5 |
Computer Aided Design/ Design of Machine Elements |
25 Computer with Design Softwares |
| 6 |
Dynamics of Machines |
1. Static & Dynamic Balancing Apparatus |
| 2. Cam Analysis Machine (without Tachometer) |
| 3. Universal Vibration Apparatus |
| 4. Whirling of Shaft Apparatus |
| 5. Journal Bearing Apparatus |
| 6. Epicyclic Gear Train and Torque Holding Apparatus |
| 7. Pendulum Module |
| 8. Transverse Vibration Module |
| 9. Torsional Vibration Module |
| 7 |
Refrigeration and Air Conditioning |
1. Vapour Absorption Refrigeration System |
| 2. Air-Conditioning Tutor |
| 3. Mechanical Heat Pump |
| 4. Digital Air Velocity Anemometer |
| 5. Vapour Compression Refrigeration System |
| 6. Charts for Refrigeration and Air Conditioning |
| 8 |
Internal Combustion Engine |
1. Four stroke multi cylinder petrol engine test rig |
| 2. Charts for Internal Combustion Engine |
| 9 |
Workshop/Manufacturing Lab |
1. TIG Welding Machine |
| 2. MIG Welding Machine |
| 3. Gas Welding Machine |
| 4. Hydraulic Press |
| 5. Power Press |
| 6. Pipe Bending Machine |
| 7. Sheet Rolling Machine |
| 8. Try square(6”) |
| 9. Metal jack plane(7”) |
| 10. Hand saw(patra) (12”) |
| 11. Half round rap file(12”) |
| 12. Half round rasp file(6”) |
| 13. Carpentry wise(205 mm) |
| 14. Steel rule(12”) |
| 15. Screw driver |
| 16. Measure tape |
| 17. Combination plier |
| 18. Tap wrench(10mm) |
| 19. LN key set |
| 20. Alphabetical punch( A to Z) |
| 21. Fix spanner |
| 22. Ring spanner |
| 23. Outside calipers |
| 24. Soft face hammer |
| 25. Ball pin hammer(200gm) |
| 26. Cross pin hammer(500gm) |
| 27. Swage hammer(500gm) |
| 28. Chisel firmer(1”) |
| 29. Chisel firmer(1.5”) |
| 30. Chisel firmer(1/4”) |
| 31. Chisel firmer(1/2”) |
| 32. Mortise chisel(1/2”) |
| 33. Pipe wise |
| 34. Tape set BSW(HSS) (1/4”) |
| 35. Pipe die set(1/2”) |
| 36. Square file-polish (12”) |
| 37. Flat rough file(12”) |
| 38. Flat polish file(12”) |
| 39. Centre punch |
| 40. Half round file(12”) |
| 41. Hand hacksaw(12”) |
| 42. Try square |
| 43. Half round file(smooth +polish)(6”) |
| 44. Hack saw blade-consumable |
| 45. Triangle file smooth +polish)(6”) |
| 46. Surface plate |
| 47. Metal wise-100 mm |
| 48. 90 degree angle plate |
| 49. Drill chuck |
| 50. Anvil(50kg) |
| 51. Hand shearing machine |
| 52. Cold metal chisel(1/2”) |
| 53. Welding machine-single phase |
| 54. Hacksaw machine |
| 55. tong |
| 56. Earthling clamp |
| 57. Welding screen |
| 58. Welding gloves consumable |
| 59. Wood turning machine |
| 60. Open furnace |
| 61. Sewage block |
| 62. All Geared Lathe Machine |
| 63. Surface Grinder Machine 9``*18`` |
| 64. Universal Milling Machine 40*9 |
| 65. Medium Duty Lathe Machine 6ft. (Nos. 4) |
| 66. Medium Duty Lathe Machine 8ft. (Nos. 2) |
| 67. Shaping Machine Strock-16`` |
| 10 |
Engineering graphics lab |
1. Model of Cut Sectional Hexagonal Prism |
| 2. Model of Cut Sectional Pentagonal Prism |
| 3. Model of Cut Sectional Square prism |
| 4. Model of Cut Sectional Triangular Prism |
| 5. Model of Cut Sectional Hexagonal Pyramid |
| 6. Model of Cut Sectional Pentognal Pyramid |
| 7. Model of Cut Sectional Square Pyramid |
| 8. Model of Cut Sectional Triangular Pyramid |
| 9. Model of Cut Sectional Cone |
| 10. Model of Cut Sectional Cylinder |
| 11 |
Materials Science and Metallurgy |
1. Muffle furnace 9x4x4 , Temp Up to 900-950 C |
| 2. Tool makers microscope |
| 3. Rockwell Cum Brinell Hardness Tester |
| 4. Jominy end quench test |
| 5. Add. Acess: - Jominy Test Fixture |
| 6. Double Disc Polishing machine |
| 7. Microstructure Sample Preparation Kit |
| 8. Metallurgical microscope (Binocular) |
| 9. Inverted Trinocular Metallurgical Microscope |
| 10. Digital USB Microscopy Camera |
| 11. Microscopic Specimen Set (23 Samples) |
| 12. Dye Penetration Test Kit |
| 13. Metallurgical Lab Chart |
| 12 |
Elements of Mechanical Engineering |
1. Band break |
| 2. Internal expanding break |
| 3. Multiple clutches |
| 4. Lancashire boiler |
| 5. Babcock& Wilcox boiler |
| 6. Locomotive boiler |
| 7. Cochran boiler |
| 8. Single acting helical gear |
| 9. Two stroke diesel engine |
| 10. Four stroke diesel engine |
| 11. Two stroke petrol engine |
| 12. Four stroke petrol engine |
| 13. Green economizer |
| 14. Ball bearing set |
| 15. Knucle joint |
| 16. Cotter joint |
| 17. Lever safety value |
| 18. Spring loaded safety valve |
| 19. Pressure gauge |
| 20. Blow of cock |
| 21. Flange coupling |
| 22. Coupling model of claw clutch |
| 23. Conical friction clutch |
| 24. Vertical water tube boiler |
| 25. Lamount boiler |
| 26. Loeffler boiler |
| 27. Cornish boiler |
| 28. Sudgens super heater |
| 29. Single plate clutch |
| 30. Centrifugal clutch |
| 31. Low water safety valve |
| 13 |
Fluid Mechanics |
1. FM Model 1 |
| 2. Free and Forced Vortex |
| 3. Orifice Mouthpiece |
| 4. Reynolds Apparatus |
| 5. FM Model 2 |
| 6. Pipe Friction |
| 7. Pipe Fittings |
| 8. Venturimeter-Orificemeter & Rotameter |
| 9. Pressure Measurement Devices |
| 10. FM Model 3 |
| 11. Bernoulli’s Theroem |
| 12. Metacentric Height Appratus |
| 13. Notch Appratus |
| 14. Pitot Static Tube Appratus |
| 15. Falling Ball Viscometer |
| 16. Hydrostatic Pressure |
| 17. Friction Inclined Plane |
| 18. Pulley System |
